QUINT-BUFFER/24DC/20
Function
For all connected loads, QUINT-BUFFER provides a regu-
lated and uninterrupted 24 V DC voltage at the output for a
load current of 20 A. Once the 24 V supply voltage has been
applied, the integrated capacitor-based power storage de-
vice is charged. If the supply voltage fails, uninterrupted op-
eration of up to 4 seconds for all connected loads is guaran-
teed with the stored power.
10,0
Buffer time extension
With the decoupled input, the connected consumers can be
divided into buffered and non-buffered loads. Thus, the
buffer time, which is dependent on the output current, is ex-
1,0
1
tended. If only the critical consumers are protected, the
buffer time is markedly extended. In addition, the decoupled
input of the connected consumers protects against errors in
2
3
the internal network.
0,1
0
5
10
15
20
1 at 22,5 V
2 at 24 V
3 at 28,5 V
Output current [A]
102035_03_en
PHOENIX CONTACT GmbH & Co. KG ? 32823 Blomberg ? Germany
Phone: +49-(0) 5235-3-00 ? Fax: +49-(0) 5235-3-4 12 00 ? www.phoenixcontact.com
www.phoenixcontact.com/salesnetwork
10
